by Jared Still on May 21, 2025 8:59:42 AM
Most Oracle DBAs are probably familiar with the concept of fetch size. The fetch size is the number of rows that are fetched from the database in a single round trip.
This can have a significant impact on performance, especially when dealing with large result sets.
In sqlplus, the default fetch size is 15 rows. This can be changed using the set array size command.
In Perl, the fetch size can be controlled by setting the database handle attribute RowCacheSize: $dbh->{RowCacheSize} = 100
In JDBC, the default fetch size is 10 rows. This can be changed using the setFetchSize method on the Statement or PreparedStatement object.
In Python the fetch can be changed using the fetch_size attribute of the PreparedStatement object, or at a session level with the default_fetch_size attribute of the connection object.
This is all good to know. However, this does not really help the DBA or Performance Analyst that would like to improve the network performance of an application.
We don't usually have access to the source code, and even if we did, we would probably not be allowed to change it.
Oracle has a file that allows an easy way to change the fetch size of any applications that use Oracle libraries for connections.
This file is called oraaccess.xml and is by default located in the $ORACLE_HOME/network/admin directory.
This method works with applications using any of the following:
- Perl DBD::Oracle
- Python cx_Oracle
- Java Thick Client
- Any application that is compiled with Oracle libraries.
- C, C++
- Fortran
- COBOL
This method will not work for applications that do not use Oracle libraries for connections.
The Java Thin Client is a good example of this.
The Java Thin Client does not use the Oracle libraries for connections, and therefore does not use the oraaccess.xml file.
There are other methods that may be used to control the fetch size of applications that do not use Oracle libraries for connections, but we will not cover them here.
A well-known Oracle application that can make use of oraaccess.xml is SQL*Plus.
What is oraaccess.xml?
The oraaccess.xml file is an XML file that contains configuration settings for Oracle client applications.
It allows you to specify various parameters, including the fetch size, for all Oracle client applications that use the Oracle libraries.
For our purposes, the oraaccess.xml file will be used only to set the default fetch size for tests with sqlplus.
How to set the fetch size in oraaccess.xml
It is fairly straightforward to set the fetch size in oraaccess.xml as per the following example:
<?xml version="1.0" encoding="ASCII" ?>
<oraaccess xmlns="http://xmlns.oracle.com/oci/oraaccess"
xmlns:oci="http://xmlns.oracle.com/oci/oraaccess"
schemaLocation="http://xmlns.oracle.com/oci/oraaccess
http://xmlns.oracle.com/oci/oraaccess.xsd">
<default_parameters>
<prefetch>
<rows>100</rows>
</prefetch>
</default_parameters>
</oraaccess>
The 'prefetch' element is used to set the fetch size. The 'rows' element specifies the number of rows to fetch in a single round trip.
That's all there is to it.
Testing with SQL*Plus and mrskew
You are likely familiar with sqlplus, as it is a standard oracle tool.
Method R mrskew is a tool that can be used to test the database performance while running sqlplus (or any oracle database application) with different fetch sizes.
The entire suite of Method R tools are my go-to choice for analyzing Oracle SQL Trace files.
They can be found at Method R Workbench
BTW, these tools are free, and are available for Windows, Linux, and MacOS.
All code used in this article is available at oraaccess-xml, and so will not be included in the article.
Any rc files used with mrskew are available here: jkstill mrtools rc files
How to test
The default location for *.ora oracle configuration files is $ORACLE_HOME/network/admin. This is also where oraaccess.xml is located.
This location can be changed by setting the TNS_ADMIN environment variable to point to a different directory.
Here is how the testing will proceed:
- create and populate a test table
- the script will create a table with 100k rows, only if it does not already exist
- sqlplus will be run with sqltrace enabled
- the trace file will be fetched and analyzed with mrskew
- Use TNS_ADMIN to point to the directory where oraaccess.xml is located
- NONE: default location. In this case there is no oraaccess.xml file at OH/network/admin
- 100/oraaccess.xml: 100 row fetch size
- 500/oraaccess.xml: 500 row fetch size
- 1000/oraaccess.xml: 1000 row fetch size
Here is a sample run of the script:
$ ./compare-oraaccess-xml.sh
Creating Table arraytest
PL/SQL procedure successfully completed.
Creating rows in arraytest
PL/SQL procedure successfully completed.
TNS_ADMIN:
TNS_ADMIN: /home/jkstill/oracle/oraaccess-xml/100
TNS_ADMIN: /home/jkstill/oracle/oraaccess-xml/500
TNS_ADMIN: /home/jkstill/oracle/oraaccess-xml/1000
$
Here are the contents of the trace/ directory:
$ ls -latr trace/*.trc
-rw-r----- 1 jkstill jkstill 2358427 May 1 11:11 trace/orcl1901_ora_1358976_ARRAY-NONE.trc
-rw-r----- 1 jkstill jkstill 343126 May 1 11:11 trace/orcl1901_ora_1359072_ARRAY-100.trc
-rw-r----- 1 jkstill jkstill 74920 May 1 11:11 trace/orcl1901_ora_1359116_ARRAY-500.trc
-rw-r----- 1 jkstill jkstill 53364 May 1 11:11 trace/orcl1901_ora_1359158_ARRAY-1000.trc
Just comparing the sizes of the trace files gives us a good idea of the performance of the different fetch sizes.
Analyze the trace files with mrskew
The rc file fetch-snmfc.rc is used to analyze the trace files. This rc file will restrict the output to FETCH, EXEC calls that had the FETCH included, and SQL*Net messages to and from the client.
In each case, the FETCH and EXEC calls are grouped by name and the number of rows returned per call.
The SQL*Net messages are grouped by name only.
Default Fetch Size
The baseline is to not use any oraaccess.xml file. This means the default fetch size of 15 rows for sqlplus will be used.
We see that 6,666 FETCH calls were made that each returned 15 rows.
The total number of rows returned was 100,000.
Of particular interest is the time spent waiting on the network.
This is not because the network was slow (average wait time was 0.000397 seconds), but because the application made far too many calls to the database.
$ mrskew --rc fetch-snmfc.rc trace/orcl1901_ora_1358976_ARRAY-NONE.trc
CALL:NNNNNNNNN DURATION % CALLS MEAN MIN MAX
---------------------------------------- -------- ------ ------ -------- -------- --------
SQL*Net message from client: 2.646101 99.9% 6,671 0.000397 0.000187 0.001386
FETCH:000000015 0.001155 0.0% 6,666 0.000000 0.000000 0.000016
SQL*Net message to client: 0.000361 0.0% 6,671 0.000000 0.000000 0.000002
FETCH:000000001 0.000018 0.0% 1 0.000018 0.000018 0.000018
EXEC:000000000 0.000010 0.0% 1 0.000010 0.000010 0.000010
FETCH:000000009 0.000000 0.0% 1 0.000000 0.000000 0.000000
---------------------------------------- -------- ------ ------ -------- -------- --------
TOTAL (6) 2.647645 100.0% 20,011 0.000132 0.000000 0.001386
100 Row Fetch Size
With 100 rows, the total amount of time spent waiting on the network is reduced from 2.646 seconds to 1.671 seconds.
$ mrskew --rc fetch-snmfc.rc trace/orcl1901_ora_1359072_ARRAY-100.trc
CALL:NNNNNNNNN DURATION % CALLS MEAN MIN MAX
---------------------------------------- -------- ------ ----- -------- -------- --------
SQL*Net message from client: 1.662761 99.5% 956 0.001739 0.000231 0.002668
FETCH:000000105 0.008220 0.5% 951 0.000009 0.000000 0.000035
SQL*Net message to client: 0.000051 0.0% 956 0.000000 0.000000 0.000001
FETCH:000000100 0.000023 0.0% 1 0.000023 0.000023 0.000023
EXEC:000000000 0.000009 0.0% 1 0.000009 0.000009 0.000009
FETCH:000000045 0.000007 0.0% 1 0.000007 0.000007 0.000007
---------------------------------------- -------- ------ ----- -------- -------- --------
TOTAL (6) 1.671071 100.0% 2,866 0.000583 0.000000 0.002668
500 Row Fetch Size
With a fetch size of 500 rows, the total amount of time spent waiting on the network is reduced from 1.671 seconds to 1.530 seconds.
This is not nearly as large a gain as was seen when comparing the default fetch size of 15 rows to 100 rows.
When large amounts of data must be moved however, the difference could still be significant.
$ mrskew --rc fetch-snmfc.rc trace/orcl1901_ora_1359116_ARRAY-500.trc
CALL:NNNNNNNNN DURATION % CALLS MEAN MIN MAX
---------------------------------------- -------- ------ ----- -------- -------- --------
SQL*Net message from client: 1.524779 99.6% 200 0.007624 0.000221 0.008691
FETCH:000000510 0.006030 0.4% 195 0.000031 0.000000 0.000054
FETCH:000000500 0.000045 0.0% 1 0.000045 0.000045 0.000045
SQL*Net message to client: 0.000035 0.0% 200 0.000000 0.000000 0.000001
FETCH:000000050 0.000011 0.0% 1 0.000011 0.000011 0.000011
EXEC:000000000 0.000010 0.0% 1 0.000010 0.000010 0.000010
---------------------------------------- -------- ------ ----- -------- -------- --------
TOTAL (6) 1.530910 100.0% 598 0.002560 0.000000 0.008691
1000 Row Fetch Size
The final test was to set the fetch size to 1000 rows.
Again, the time spent waiting on the network is reduced from 1.530 seconds to 1.492 seconds.
A difference of 0.038 seconds may not be important most of the time.
This test is for a relatively small amount of data (100k rows).
If this test were for 500 million rows, the difference would be 190 seconds.
This may be important for large volumes of data.
$ mrskew --rc fetch-snmfc.rc trace/orcl1901_ora_1359158_ARRAY-1000.trc
CALL:NNNNNNNNN DURATION % CALLS MEAN MIN MAX
---------------------------------------- -------- ------ ----- -------- -------- --------
SQL*Net message from client: 1.485908 99.6% 103 0.014426 0.000205 0.015652
FETCH:000001005 0.006022 0.4% 98 0.000061 0.000000 0.000138
FETCH:000001000 0.000083 0.0% 1 0.000083 0.000083 0.000083
FETCH:000000510 0.000035 0.0% 1 0.000035 0.000035 0.000035
SQL*Net message to client: 0.000017 0.0% 103 0.000000 0.000000 0.000002
EXEC:000000000 0.000011 0.0% 1 0.000011 0.000011 0.000011
---------------------------------------- -------- ------ ----- -------- -------- --------
TOTAL (6) 1.492076 100.0% 307 0.004860 0.000000 0.015652
Conclusion
The oraaccess.xml file is a powerful tool that can be used to control the fetch size of Oracle client applications.
It is simple to use and can have a significant impact on performance, especially when dealing with large result sets.
